Radar Speed Sign – Portable

45 second deployment
Lightweight with handle for easy mobility
High visibility display
Supplied with heavy duty tripod and charger
Quality LiFe04 battery
40 hours of continuous operation
Reduces the speed of traffic by creating awareness of speed limit
Increases visibility of the message and improve safety
Signs manufactured to Australian Standards using reflective material
IP65 Waterproof design
Day or night operation
A Bluetooth APP (android) allows control over the full dot matrix display area to change the posted speed limit
2-year warranty for faulty workmanship or component failure not influenced by external means.

Product

Solar
Lighting
Designs

Solar Lighting Designs

©2024

Product Description.

Radar Speed Sign – Portable

The SLD Portable Radar speed sign is deployed in under 45 seconds and powered by a long life LiFeP04 battery that is recharged quickly from the supplied fast charger. No solar panel is required. The design incorporates the battery, LED sign face and radar into one streamlined and efficient product that is designed to sit atop the sturdy tripod. There is no cabling to be run, no battery box to be fitted, the complete unit is simply installed to the tripod and commissioned. A fully charged battery typically returns a running time exceeding 40 hours of continuous operation.

Technical Data

SKU	SRSS003
LED Screen	320 x 320mm
Sign	900 x 600 x 100mm
Display Colour	Red/Green
LED Wavelength	Red:620/Green:525
Luminance Density	≥6000cd/m2 Outdoor Highlighted
Viewing Angle	60°
Viewing Distance	1 – 200 Mtrs)
Speed Range	1 – 99 km/h
Fixed Sign Material	Aluminum/3M reflective
Radar Frequency	K-Band, 24.1250Ghz
Radar Range	1 – 150 Mtrs
Radar Accuracy	<±1Km/h
Battery Specifications	24 Ah 12v (288Wh) LiFeP04
Power Consumption	Max 11W Average ≤2W
Solar Panel	18v 60w
Autonomy	>48 Hours (setting dependent)
Recharge	< 6 Hours
Mounting Height	2 – 2.5 Mtrs
Display Brightness	Automatic Dimming
Waterproof Rating	IP65
Warranty Period	2 years

Video

Printable Data Sheets

SOLAR RADAR SPEED SIGN – PORTABLE SPECIFICATION

Additional Information

WHAT IS A LUMEN?In simple terms, Lumens are a measure of the total amount of visible light from a lamp or light source. The higher the lumen rating, the “brighter” the lamp will work.FAMILIAR EXAMPLES

A typical 4 x D cell battery maglite will emit approx. 70 lumens
The average path light using 2-3 LEDs emits 15-18 lumens
A 25W incandescent globe emits approximately 160 lumens
